SKU: OSD-ICE800WRS
OSD ICE800WRS8" Weather-Resistant 150W Outdoor/Indoor In-Ceiling Speaker Pair
This 8-inch in-ceiling, weather-resistant speaker pair is ideal for high-humidity areas, including outdoor patios, bathrooms, laundry rooms, and covered porches! With high power handling and an 8-inch polypropylene woofer in each, these speakers deliver superior sound that covers large spaces. With swivel tweeter adjustment, you can easily create sweet spot for your listening area. Better crossover, tweeter and woofer materials add sound quality. The aluminum grill cover is rust-resistant for wet application.These weather-resistant indoor/ outdoor in-ceiling speakers work well with a CL3 in-wall rated speaker wire, which is designed to run inside walls.
Pivoting Tweeter
The job of the tweeter is to deliver the higher frequencies of music and soundtracks. The tweeter is also adjustable, meaning it can be aimed toward the listening area. This can make a big difference in sound quality especially for dialog and higher frequencies.
How Does this Speaker Mount in the Ceiling?
Customers often ask us if they need special installation mounting brackets on their OSD ceiling speakers. The answer is no and here’s why. All our in-ceiling speakers feature a dog leg (L-shaped) mounting system that is part of the frame. Before you install the speakers, remove the grille and you’ll see several the mounting screws near the front frame. These screws need to be loosened to activate the dog leg clamps. Use a screwdriver to loosen (turn to the left) these screws and the clamp will come loose. When the speaker is in position in the ceiling, tighten (turn to the right) the screw and the speaker will be secured to the ceiling.
What Type of Speaker Wire and What Gauge?
Wiring is not included with in-ceiling speakers so you will have to purchase some. We recommend our OSD Audio CL3/FT4 cable that is UL (fire) rated for in-wall and outdoor speaker installs. This type of cable includes a heavy-duty outer jacket approved for in-wall/in-ceiling installation. The high-quality plastic jacket is also very flexible so it's easy to run the wires inside the wall. As for the gauge, for runs up to 100 feet for background music, 16-gauge will be fine. If the run is approaching or exceeding 100 feet, we suggest 14-gauge wire.
Testing the Sound Quality of In-Ceiling Speakers
Many customers like to test the sound quality of their new OSD Audio in-ceiling speakers before they install them. Keep in mind, however, that these flush-mount speakers are designed to be used in the wall or ceiling. Uninstalled in-wall/in-ceiling speakers will sound weak and tinny because without the proper enclosure (in this case your house wall) the speaker can’t produce the sound pressure level it needs. If you want to try them out, we recommend mounting the in-ceiling speakers into a box of about 3 cubic ft. or larger; or simply mount them in the ceiling and then listen. This will give you an accurate measure of the sound quality.
For a retrofit installation, no construction bracket is needed.
Warning: California's Proposition 65
Warning:
This product can expose you to chemicals, including vinyl chloride, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
- Speaker Type: 8" Weather Resistant Indoor/Outdoor Ceiling Speaker
- Woofer: 8" Polypropylene Cone with Santoprene Surround
- Tweeter: 1" Pivoting Polycarbonate Dome
- Frequency Response: 38Hz-20kHz
- Power Handling: 150W
- Sensitivity: 90 dB
- Impedance: 8 Ohms
- Weather-resistant for High Moisture Situations
- Perfect for Outdoor or Indoor Use
- Spray Paintable Rust-Resistant Aluminum Grille Included
- Inputs: Spring Loaded Binding Posts
- Install-friendly Dog Ear Installation Brackets
- See New Construction Brackets For Compatibility
- Diameter & Depth: 10.24" x 4.13"
- Cutout Diameter: 9.06"
- Sold As: Pair
- Warranty: 10 Years
49 Questions asked
Have a Questions?
What's on your mind?
Chris • 12/17/2019, 2:17:43 PM
I am interested in spray painting the speaker grill and trim ring of the speaker. Once the grill is removed, I found that it has a felt-like overlay inside. Any suggestions on how to paint these items, without coating the felt overlay, not sure i it is removable. Thanks
Customer Service • 12/17/2019, 2:17:43 PM
Hi Chris,
There really is no way to paint it correctly as long as that cloth is attached. It is best to remove the cloth as gently as possible to keep it intact and then paint the grill. After you have painted it and it has dried, you can use an adhesive spray to reconnect the cloth to the speaker, although it is not required. Thanks!
BM
2749
Jorge • 12/17/2019, 2:17:43 PM
Will this guys be OK in very low temperatures in winter time in the northeast?
Customer Service • 12/17/2019, 2:17:43 PM
Hi Jorge,
We haven't seen any problems with our customers in the northeast as of yet so it should be fine.
Antony Lulic • 12/17/2019, 2:17:43 PM
are these 150 watt rms or peak?
Customer Service • 12/17/2019, 2:17:43 PM
Hi Antony,
These speakers are 150 watts peak.
CS
2940
Jun • 12/17/2019, 2:17:43 PM
Hi
I have a question for you.
Can i use this speaker for iphone?
I just connect it by bluetooth between ceiling speaker and iphone in my bathroom.
If i buy this speaker, it ll be ok everything?
Please,give me information.
I ll do the renovation for my bathroom .
I ll install ceiling speaker for my iphone.
Thanks
Jun
udt2804@hotmail.com
Customer Service • 12/17/2019, 2:17:43 PM
Hi Jun,
You need an amplifier or receiver to power these speakers. You can't power them from a phone nor can you connect to them via Bluetooth. You would need a Bluetooth receiver connected to an amplifier that is wired to these speakers to do what you want to do.
Bob Matthews • 12/17/2019, 2:17:43 PM
I am looking for 2 sets of these speakers, since they are "out of stock" when is the next shipment? Also do you have a comparable unit that I might be interested in. Exterior use, but not exposed to extreme moisture. Thanks Bob
Customer Service • 12/17/2019, 2:17:43 PM
HI Bob:
I would recommend looking at the MK840. It features a weather resistant Powder Coated Grill and a Polypropylene cone. I would recommend using a little silicone around the inside of the frame when you mount it in the enclosure. Definitely a step up over the ICE-800 WRS in components and design. And they are in stock...
TL/3167
